Promax 100m³/h Mobile Concrete Batching Plant

The Promax M100 TWN Mobile Concrete Batching Plant is an excellent solution for temporary needs with its high-efficiency rapid production capacity, easy transport, and quick installation features. Trusted by leading contractors worldwide for short-term construction projects, this mobile-designed concrete plant requires minimal infrastructure investment and allows for a quick start to production.

Advantages:

• High-Efficiency Rapid Production: Capable of producing 100 m³ of compacted concrete per hour.
• Easy Transport: The mobile design allows for quick and easy transport from one location to another.
• Minimal Infrastructure Investment: Requires minimal infrastructure for installation.
• Quick Installation: Can be set up and ready for production in a short period.

Developed through extensive R&D, the Promax M100 TWN is a high engineering product that combines the power and capacity of stationary plants with the advantages of mobility, changing the habits of low-capacity production in mobile concrete plants.

Technical Information:

• Plant Capacity:
  • Compacted Concrete Capacity: 100 m³/h
• Mixer Specifications:
  • Mixer Type: Twin Shaft
  • Dry Capacity: 3000 liters
  • Mixer Capacity: 2000 liters
  • Motor Power: 2 x 37 kW
• Aggregate Bunker:
  • 4 Compartments: 4 x 11.25 m³
• Mixer Conveyor Belt:
  • Width: 1000 mm
  • Length: 11,500 mm
  • Motor Power: 15 kW
• Cement, Water, Additive Weighing Systems:
  • Aggregate Weighing: 5000 kg
  • Cement Weighing: 1100 kg
  • Water Weighing: 600 liters
  • Additive Weighing: 50 kg
• Cement Silo:
  • Capacity: 75-100-150-200 tons
  • Number of Silos: 1, 2, 3, 4 units
• Cement Silo Equipment:
  • Screw Diameter: 273 mm
  • Screw Length: 7000 mm
  • Motor Power: 11 kW
  • Silo Top Filter
  • Manual Lever Valve
• Air Compressor:
  • Capacity: 500 liters/min
  • Operating Pressure: 7-8 bar
  • Motor Power: 5.5 kW

The Promax M100 TWN Mobile Concrete Batching Plant provides high efficiency and fast production for short-term projects, offering professional solutions. Contact us for more information and to request a quote.
